Solaris Trendelenburg Treatment Table 3 Section
Tilt a patient head-down or head-up at the touch of a switch - meet the Solaris Trendelenburg Treatment Table 3 Section
Built for clinics and procedure rooms that need to tilt a patient head-down or head-up, not just raise and lower the couch.
Four motors drive the height, backrest, legrest and tilt, so every position change is a button press.
A hand switch controls all functions. A footswitch controls height only, so your hands stay on the patient.
Solaris Trendelenburg HiLo Couch 3 Section built to hold up in daily practice use
Trendelenburg tilt moves 17° each way. The backrest moves from -23° to 75° and the legrest from -30° to 77°.
Super strong construction with a heavier base frame prevents tipping, and 100mm locking castors hold the couch where you put it.
A 65mm padded top keeps patients comfortable, and a paper roll dispenser sits behind the backrest.
A hand switch holder bracket is on the backrest, and a safety side rail bracket is included. The couch is maintenance free.
What you actually need to know about the Solaris Trendelenburg Couch 3 Section before ordering
How long will it last, and what's covered if something goes wrong?
The frame carries a 5 year warranty. Contact us on how a claim works.
Is 225kg enough for my patients?
The safe working load is 225kg. If you regularly treat heavier patients, choose a higher-rated table, such as one labelled "Bariatric" for lift capacity.
Will it stay put once it's in position?
Yes. 100mm locking castors hold it in place, and the heavier base frame is built to prevent tipping.
How long will it take to arrive?
When in stock, it takes 2-10 business days from order date until delivery. Contact us for the latest delivery estimate before you order.
Product Info
The Solaris Trendelenburg 4M couch is fully motorised for effortless adjustment of height backrest legrest and tilt. A hand switch controls all functions and an additional footswitch controls the height only.
3 Section upholstered top
4 Motors for height, backrest, legrest & tilt adjustment
Hand switch controls all functions & additional footswitch controls height only
Super strong construction with heavier base frame to prevent tipping
Paper roll dispenser behind backrest
Hand switch holder bracket on backrest
Safety side rail bracket included
100mm Locking castors
65mm Thick padded top for patient comfort
Maintenance free, no need for regular lubrication or adjustment
5 Year frame warranty
Blue quality vinyl upholstery. Charcoal grey available upon request.
Colours
The colours shown below are a guide only. They will differ from screen to screen. Do not rely on a printed version of on-screen colours. If you are fussy about colour, please request a real sample.
Default Vinyl: Blue
Contact us if you want Charcoal Vinyl
Get set up with confidence
Add to Cart. Live chat available if you want to confirm colour, delivery timing, or warranty claims before you order.
Specifications
| Category | Detail |
|---|---|
| Overall Dimensions | 1865mmL x 710mmW |
| Backrest Dimensions | 640mmL x 710mmW |
| Middle Dimensions | 547mmL x 710mmW |
| Legrest Dimensions | 632mmL x 710mmW |
| Height Adjustment | 460mm – 924mm |
| Trendelenburg Tilt | -17° / 17° |
| Backrest Movement | -23° / 75° |
| Legrest Movement | -30° / 77° |
| Castor Diameter | 100mm |
| Safe Working Load | 225kg |
